Motor typeBrushless DC motorGearbox typePlanetary Pole8Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:65 ~1: 944Peak current2.6ANo load speed3000rpmNominal speed2100rpmPermissible load range2N.m-20N.m for S1 duty cycleRated power11W

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 104mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.50A; 1.20ANo load speed2000rpm; 3500rpmNominal current6.0A; 10.0ANominal speed1700rpm; 3000rpmPermissible load rangeup to 30.0N.m for S1 duty cycleNominal power110.0W; 200.0WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetaryPole4Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.71 ~ 1:139Peak current5.21A; 7.78ANo load speed4000rpm; 5000rpmNominal speed3000rpm; 4000rpmPermissible load range0.5N.m-15.0N.m for S1 duty cycleRated power50W; 70W

Motor typeBrushless DC motorGearbox typePlanetaryPole4Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.71 ~ 1:265Peak current3.47A; 4.44ANo load speed4000rpm; 5000rpmNominal speed3000rpm; 4000rpmPermissible load range0.5N.m-15.0N.m for S1 duty cycleRated power30W; 40W

Motor typeBrushless DC motorGearbox typePlanetaryPole4Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.71 ~ 1:369Peak current2.31A; 3.47ANo load speed4000rpm; 5000rpmNominal speed3000rpm; 4000rpmPermissible load range0.5N.m-15.0N.m for S1 duty cycleRated power20W; 30W

Motor typeBrushless DC motorGearbox typePlanetary Pole8Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.71~1:369Peak current6.2A; 11.8ANo load speed4100rpm; 4000rpmNominal speed3000rpmPermissible load range0.5N.m-15.0N.m for S1 duty cycleRated power22W; 50W

Motor typeBrush commutated DC motorGearbox typePlanetary DiameterGearbox: 42mm; DC motor:42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.71 ~1:427No load current0.15A; 0.2ANominal current0.75A; 1.2ANo load speed3000rpm; 4000rpmNominal speed2500rpm; 3500rpmPermissible load range1.0N.m ~ 10.0N.m for S1 duty cycleNominal power11.5W; 20WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 104mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.30A; 0.60ANo load speed2000rpm; 3500rpmNominal current3.0A; 6.50ANominal speed1700rpm; 3000rpmPermissible load rangeup to 30.0N.m for S1 duty cycleNominal power57.0W; 110.0WIP ratingup to IP68

Motor typeBrush commutated DC motorGearbox typePlanetary DiameterGearbox: 42mm; DC motor:42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.71 ~1:305No load current1.2A; 0.6ANominal current6.7A; 4.2ANo load speed7000rpmNominal speed5200rpmPermissible load range1.0N.m ~ 10.0N.m for S1 duty cycleNominal power47.9W; 65.3WIP ratingup to IP68

DC WORM GEARED MOTOR 76ZYT/73WJ TYPICAL SPECS.:·  Voltage 24V DC·  Current approx. 5A·  Motor Output Power 60W·  Rated Speed 60rpm·  Rated Torque 4.8N.m·  Gearbox Reduction Ratio 57 : 1·  Voltage 24V DC·  Current approx. 5A·  Motor Output Power 60W·  Rated Speed 180rpm·  Rated Torque 1.6N.m·  Gearbox Reduction Ratio 17 : 1
