DC PLANETARY GEARMOTOR 82JXZ/80ZY SPECS & FEATURE:Voltage 24V DC or 12V DCRated Speed 2~10RPMRated Torque 180N.m for intermittent running, 120N.m for continuous runningWith/Without Encoder or BrakeIP Class IP54, IP55, IP65 or IP68

DC PLANETARY GEARMOTOR 82JX1200K/90ZY SPECS & FEATURE·  90mm OD DC Brushed Motor ·  82mm OD Planetary Gearhead·  Voltage 24V DC·  Rated Speed 2700RPM·  Rated Current 20.6A·  Gear Ratio 90 : 1·  Rated Speed 30RPM·  Rated Torque 84N.m·  High Temp. & High Humidity Use· Voltage 90V DC· Rated Speed 4200RPM· Rated Current 5.4A· Gear Ratio 14 : 1· Rated Speed 300RPM· Rated Torque 9.46N.m· High Temp. & High Humidity Use

DC PLANETARY GEARMOTOR 56JX300K/71ZY110 SPECS & FEATURE·  71mm OD DC Brushed Motor ·  56mm OD Planetary Gearhead·  Voltage 12 ~ 230V DC·  Gear Ratio 3.6 ~ 326 : 1·  Rated Speed 3 ~ 900RPM ·  Power up to 100W

High IP Class DC Motors & Gear MotorsMotor OD: 45mm, 63mm, 73mm, 80mm, 90mm, 100mm, 110mmGear Motor Rated Torque up to 600N.mIP44, IP54, IP55, IP65 or IP68Typical Application: Used for Water, Outdoors, Auto etc.Fox example: Pool Cover Motor, Solar Tracker Motor, Truck & Car Accessories.

DC PLANETARY GEAR MOTOR 80ZY125-1231CD/110JX646G3072 TYPICAL SPECS.:· Voltage 12V DC· No-Load Current 2A· Max Load Current 18A· No-Load Output Speed 4.8RPM· Rated Output Speed 3.8RPM· Rated Output Torque 200N.m for Continuous Running· Rated Output Torque 300N.m for Intermittent Running· Gear Ratio 426/1· With Encoder & Brake

 DC PLANETARY GEAR MOTOR 96ZY-22020/120JX426G30 TYPICAL SPECS.:· Voltage 220V DC· Motor Rated Speed 1500RPM· Motor Rated Torque 1.5N.m· Rated Output Speed 3.5RPM· Rated Torque 460N.m for Continuous Running ( 600N.m for Intermittent Running )· Gear Ratio 426/1

High torque Endless SPA pool & tubs cover lift DC worm and planetary gear motor;High torque DC worm and planetary gear motor for SPA pool & tubs fully automatic electric cover lift systemTypical model: 52ZY12-2435HU-3/52JXM50G/RVH-52(combine with both worm gearbox and planetary gearbox)Only DC Planetary gear motor specs.: Rated voltage: 24V DCPlanetary gear ratio: 50:1No-load current: within 1ANo-load speed: 70rpmWorking speed: 50rpmWorking torque: 21N.m(S2, 1min.)Working current: within 10AIP rating: IP55 Final DC Worm and Planetary gear motor specs.: Rated voltage: 24V DCgear ratio: 2500:1No-load speed: 1.4rpmWorking speed: 1rpmWorking torque: 360N.mDuty cycle: S2 – 2min.

STAIRLIFT DC RIGHT ANGLE GEAR MOTOR 90ZY165CD-133WJ SPECS AND FEATURE:· Voltage 24V DC· No-Load Speed 20rpm· Max. Efficiency 34.38%· Max. Efficiency Point 53.69N.m@16rpm· Stall Torque after Gearbox 319.33N.m ( Stall Current 55.0A )· Gear Ratio 160/1STAIR LIFT DC GEAR MOTORSTAIRLIFT GEAR MOTORSTAIRLIFT MOTOR

42ZYN NdFeB Magnet DC BRUSH MOTOR TYPICAL SPECS. *  Motor OD: 42mm *  Voltage: 24V DC *  No-load Speed: 4350RPM *  No-load Current: 0.5A *  Rated Output Power: 60W *  Rated Speed: 3300RPM *  Rated Torque: 180mN.m *  Max. Efficiency: 84% *  Custom Higher Power is available upon request (Longer Body or Stronger NdFeB Magnets)Compact Size High Power NdFeB Magnet brushed DC Motor 42ZYN

110ZY195 HIGH VOLTAGE DC BRUSH MOTORS TYPICAL SPECS.:·  Rated Voltage 115V DC (or 220V DC )·  Rated Current <= 6A (or <=4A )·  Rated Output Speed 2630-2900RPM·  Rated Torque 1.8N.m·  Rated Output Power 550W·  Duty Cycle S1·  Insulation Class B·  Rotation: Clockwise (view from the end of output shaft )·  Rated Voltage 120V DC·  Rated Current <= 6A·  Rated Output Speed 1800-2000RPM·  Rated Torque 2.6N.m·  Rated Output Power 550W·  Duty Cycle S1·  Insulation Class B·  Rotation: Clockwise (view from the end of output shaft )·  With Gearbox Available·  Customized shaft & front cover and Customized specs. available upon request

DYD year 2024 Sales promotion wheelchair power assistant drive, caravan mover,clay pigeon trap universally used DC right angle gear motor; Ready-made German warehouse stock universally-used DC worm gear motorsThis type is especially suitable to supply European after-sales markets. Ready-to-ship storage place: Berlin, GermanyQty.: 1000 pcsTechnical specs.:Rated voltage: 24V DCRated torque: 5N.mRated speed: 167RPMRated current 15AGear ratio: 25:1Negotiations to adjust or change shaft dimenions are possible based on the needed quantities.CE, UKCA, RoHS, Reach approvalDimensions:
