1. Voltage: 12 ~ 60VDC2. Gear Ratio: 18:1, 36:13. DC Motor Available ( OD ): 60mm, 52mm, F45mm4. With 2 Hall Sensors5. Reach, CE, RoHS compliance6. Application: Table Lift, Furniture, Others7. Solid Shaft Available Upon Request DC RIGHT ANGLE GEAR MOTOR F45ZY-23JW SPECS AND FEATURE:·        Voltage 29V DC·        No-Load Speed 100rpm·        Max. Efficiency 38.3%·        Max. Efficiency Point 17.13Kg.cm@83rpm·        Stall Torque after Gearbox 100.79Kg.cm ( Stall Current 6.60A )·        Gear Ratio 36/1

Motor typePermanent magnet DC MotorGearbox typeWorm/Right angleSizeDC motor:63mm,Gear motor:63mmNo-load Current0.32A;0.40ANominal voltage12V/24V or CustomizedGear ratio 1:10;1:15;1:30;1:50Nominal speed1550rpm;2500rpmPermissible load rangeUp to 8N.m for S1 duty cycleNominal power20W;30W

DC RIGHT ANGLE GEAR MOTOR 80ZY112-3644 SPECS AND FEATURE: Motor Size 80mm ODGearmotor Output Power 100W Voltage 36V DC ( or 12V, 24V )Rated Speed 100RPMRated Torque 9.55N.m Gear Ratio 35/1Duty Cycle: Continuous

Motor typePermanent magnet DC MotorGearbox typeWorm/Right angleSizeDC motor:63mm,Gear motor:63mmNo-load Current0.32A;0.40ANominal voltage12V/24V or CustomizedGear ratio 1:10;1:15;1:30Nominal speed2600rpm;2700rpmPermissible load rangeUp to 10N.m for S1 duty cycleNominal power70W;100W

Motor typePermanent magnet DC MotorGearbox typeWorm/Right angleSizeDC motor:83mm,Gear motor:90mmNo-load Current0.8A;0.9ANominal voltage12V/24V or CustomizedGear ratio 1:12.5;1:16;1:25;1:32;1:40;1:50Nominal speed1700rpm;2500rpmPermissible load rangeUp to 10N.m for S1 duty cycleNominal power42W;77W

DC RIGHT ANGLE GEAR MOTOR DYD29530L01 SPECS AND FEATURE:Motor Size 92mm ODVoltage 24V DCNo-Load Speed 30RPMRated Speed 25RPMRated Torque 18N.mGear Ratio 49/1 Duty Cycle: Continuous

Motor typePermanent magnet DC MotorGearbox typeWorm/Right angleDiameterDC motor:80mmNo-load Current1.5ANominal voltage12V/24V or CustomizedGear ratio 1:125;1:160;1:250Nominal speed2000rpmPermissible load rangeUp to 20N.m for S1 duty cycleNominal power84W

                                Motor typePermanent magnet DC MotorGearbox typeMixed planetary and worm gearboxDiameterDC motor:60mmNominal voltage12V/24V or CustomizedCombined Ratio1:106;1:136;1;325;1:450;1:375;1:1175Nominal speed2rpm;4rpm;6rpm;8rpm;11rpm;14rpmPermissible load rangeUp to 20N.m for S1 duty cycleNominal powerup to 150W

GEARMOTOR SPECS AND FEATURE: Motor Size 54mm OD x 95mm LengthMotor Power up to 40W15 : 1 or 72 : 1 gear ratio.Optional: Encoder / Brake / Connector



DC RIGHT ANGLE GEAR MOTOR 70ZY97-24180 TYPICAL SPECS.:Voltage 24V DCRated Output Power 90WRated Torque 4.8N.mRated Speed 180RPM

DC WORM GEARED MOTOR 73ZY-90WJ TYPICAL SPECS.:Voltage 48V DCRated Torque 7N.mRated  Speed 88RPMGear Ratio 25/1orVoltage 48V DCRated Torque 11N.mRated  Speed 55RPMGear Ratio 40/1
