Spreader Motor Auger Motor 12V 3/4 HP 1750 RPM D6872

Spreader Motor Auger Motor 12V 3/4 HP 1750 RPM D6872 GENERAL SPECS.·  Motor OD: 130MM·  Voltage: 12V DC·  Rated Output Power 3/4HP (or 1/2HP )·  Rated Output Speed: 1750RPM ( or 1200RPM, or 470RPM)·  Duty cycle S1·  Insulation Class F·  Customized shaft & front cover (NEMA 56C,  IEC61/71/80 B5/B14, NEMA 143TC/145TC) available upon request

P/N 138449 D-300 RV Slide-Out Motor (3/4 inches Drive)

P/N 138449  63ZY-160JB D-300 RV Slide-Out Motor (3/4 inches Drive) TYPICAL SPECS.:Voltage 12V DC400 In-Lbs @10 Amps @ 11.5RPM850 In-Lbs @ 17 Amps @ 7.0RPMWith A Power-Off BrakeGearbox Ratio 162.7/1 ( Other Ratios Available Upon Request )1pc per EPE carton, carton size 314*163*195mm, 5.0KGS/pcPart # LC138449

LG-142178 Trailer Landing Gear Motor Heavy Duty Drive P/N 241795

Replacement Motor for Lippert LG-142178 / M6V-241795 / M-9000-PK Trailer Landing Gear Motor Heavy Duty DriveReplacement Motor for Stromberg Carlson Electric Landing Gear - 5,500 lbsItem # LG-142178 / M6V-241795 / M-9000-PK12V DC GEARMOTORNo-load Current 2.7ANo-load Speed 130rpmMax. Efficiency Point DataCurrent 10ASpeed 117rpmTorque 6N.mMax. Efficiency 61%Working Point DataCurrent 25ASpeed 80rpmTorque 17N.mGEAR RATIO 42.4:1With Current Limiting Protector ( 30Amps )

Item # BD1046130-00, 500370, 1824200100, 1824210100, 1046131, 1046130

Replacement Gear Motor for Bulldog Electric Powered-Drive KitItem # BD1046130-00 , 500370, 1824200100, 1824210100, 1046131, 104613012V DC GEARMOTORRED WIRE LEAD +12V CW ROTATION, VIEW FROM DIRECTION A18.75 FT-LBS @ 14AMPS AND 32RPMGEAR RATIO 99:11 piece per EPE foam cartonWeight 5.5KGS/pcCarton size 471*256*141mmP/N 500370  ( 1046130 )

RP-785615 RV Slide Out Motor 18:1 Ratio M-8910

RP-785615  RV Slide Out Motor 18:1 Ratio M-8910Model: 63ZY116-1257/160JB18GItem # RP-785615, M-8910, 014-132682, LC295380Voltage 12V DCNo-load Current 2.72ANo-load Speed 315rpmMax. Efficiency Point Data:Current 21.64ASpeed 270rpmTorque 5.49N.mMax. Efficiency 60%Gear Ratio 18 : 1With Current Limiting ProtectorUL, CE, Reach and RoHS approvalOptional components: magnetic/optical encoder; brake; connectorCustomized shaft dimensions and technical specifications are available upon requestedTypical Applications: High-Speed Power Stabilizer Jack, RV Leveling System, Trailer Leveling System

( P/N 364262 ) 42mm Mid Torque RV In-Wall Slide-Out Motor with Brake 1510000227

(Part # 523900) P/N 368417 P/N 368190 63ZY-160JB RV In Line DC Gear Motor 523823

P/N 368417 P/N 368190  63ZY-160JB RV In Line DC Gear Motor ( Part # 523900) 523823 TYPICAL SPECS.:1)Voltage 12V DC400 In-Lbs @10 Amps @ 11.5RPM850 In-Lbs @ 19 Amps @ 8.5RPMWith A Power-Off BrakeGearbox Ratio 162.7/1 ( Other Ratios Available Upon Request )Part # 523900 2)Voltage 12V DC400 In-Lbs @7.5 Amps @ 8.5RPMWith A Power-Off BrakeGearbox Ratio 415/1 ( Other Ratios Available Upon Request )Revised 1: R17/R13.5 (Original R20/R16.5);Revised 2: Allen bolts (Original Hexagon bolts );Revised 3: 11mm U-shaped holes (Original 5.3mm diameter screw holes );Revised 4: Grey rubber boot (Original Black rubber boot )Replaces Power Gear motors:523900, 521976W, 521976, 523983, 524327, 524097, 520819, 522967, 523036, 523931, 524246, 523498, 523432, 523143, 523529, 524094, 52441, 368200, 383755

P/N 236575, 287298 RV In Wall Slide-Out Actuators Motor

Salt Spreader Motor Gear Box D6106 D6107 D6107-06 D610706

DC SALT SPREADER MOTOR GEAR BOX D6106 D6107 D6107-06 D610706 TYPICAL SPECS.:·  Rated Voltage 12V DC ·  Power 239W·  Rated Speed 762RPM·  Rated Torque 3N.m·  Gear Ratio 8:1

352338 Power Stabilizer Jack Motor C-800 ( P/N 337199 )

Trailer Landing Gear DZ84ZYC11

DC SPUR GEAR MOTOR DZ84ZYC11 SPECS AND FEATURE:Motor Size 84mm ODVoltage 12V DCRated Torque 100N.m    Max. 136N.mRated Current 40A    Max. 55ARated Speed 22RPMWork Duty 5 Mins.Max. Efficiency > 55%Gear Ratio 141/1 Waterproof Class IP66With Build-in ControllerApplication - Trailer Landing Gear, Trailer & Truck Front to Back Power Tarp System

Salt Spreader Motor 3000966

DC SALT SPREADER MOTOR 3000966 GENERAL SPECS.·  Motor OD: 78MM·  Voltage: 12V DC·  Rated Torque 0.45N.m·  Rated Speed: 175RPM·  No-Load Speed 885RPM·  Rated Current 4.0Amps

  • «
