DYD PLANETARY GEARHEAD ( OD mm ): 16mm, 22mm, 24mm, 28mm, 30mm, 32mm, 36mm, 40mm, 42mm, 45mm, 48mm, 52mm, 56mm,  60mm, 72mm, 80mm, 82mm,  92mm, 110JX, 120JXDYD MOTOR TYPES: Brushed DC Motor, Brushless DC Motor, Stepping Motor, AC Motor.Multiple Ratios available Low noise levelSmooth and Quiet Operation for Continuous UseHigh Rated Torque up to 1000N.mCustomized Shaft Material and Shaft Dimensions Available.Extremely High Efficiency with Only 8% Loss Per Train!

Tarp Gear Motor w/Chrome Cover Dump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.600W TARP MOTOR 80ZYT-12/JW-7A SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 600 in-lbs)90:1 gear ratio.No-load Speed 55RPM / Rated Speed 40 RPM (+/-5RPM)Power 600W ( L = 240mm ) or 900W ( L = 270mm, Model 80ZYTS-12/JW-7A )Epoxy sealed gearbox maintains lubrication.2-1/2" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.Waterproof Level IP65100% tested for quality control.Optional 24V DC, Gear Ratio 60:1 or 45:1, 900W/1.2HP, 1200W/1.5HP, 2.0HP, 2.5HPAmbient temperature of minus 40° available upon requestReplaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

Industrial Door Locking DC Gear Motor / DC Linear ActuatorModel: DYD38ZY73-1223-250-30Typical Specs.: 12VDC, Force 250N.m, No-Speed 25mm/S, Stroke 30mmApplication: Industrial Door Locking

Low Speed IP66 DC Planetary Gear Motor for Solar Tracking SystemGeneral technical specs.:Voltage: 24V DC or customizedOptional IP Rating: IP54, IP55, IP65, IP66 or customer's needsRated torque up to 35N.m for continuous runningMax. torque up to 150N.mCertificates: ISO9001, CCC, CE, EAC, UKCA, RoHS; ReachCustomized shaft & flange dimensions and technical specifications are available upon requested.One Typical Model:63ZY105-2420/52JXM176G12J30Gear Motor:Voltage: 24V DCGear Ratio: 176:1Rated Speed: 9rpmRated Torque: 25N.mRated Current: within 2.5AIP Rating: IP66Operation Temp.: -40℃ ~ 70℃

800W HYDRAULIC OIL PUMP DC MOTOR GENERAL SPECS.Voltage 24V DCNo-Load Speed  4400RPMNo-Load Current < 3.5ARated Output Speed 3100RPMRated Output Torque 2.45N.mRated Output Power 800WRated Current < 60AInsulation Class FDuty cycle S2 - 2min.Customized shaft & front cover available upon requestApplication: AGV, Automobile cab steering, Rising-lowering lifting system, Electric forklift, Lifting pump station, Hydraulic power leveling system etc.

Tarp Gear Motor 1.8HP 80ZYT-12/JW-5A with Chrome CoverTarp Gear Motor 1.8HP 80ZYT-24/JW-5A with Chrome CoverTarp Gear Motor 2.1HP 80ZYTS-12/JW-5A with Chrome CoverTarp Gear Motor 2.1HP 80ZYTS-24/JW-5A with Chrome CoverDump Truck Tarp Motor ( Canvas Engine, Tipper Sheeting Motor, Dura-Torque Gearmotor, Durabuilt Motor), fits most automatic tarp systems.MOTOR SPECS AND FEATURE (GEAR RATIO 90:1): 3 year warrantyHi-torque, direct drive 12VDC (or 24VDC) motorNo-load current 13.786A @ no-load speed 57rpmMaximum Efficiency 32.47%47rpm @ Max. efficiency 41.19N.m ( 360 in-lbs ) @ Max. efficiencyOutput Power 200W @ Max. efficiencyStall Torque 225.29N.m (Lock-rotor Torque )Epoxy sealed gearbox maintains lubrication.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.100% tested for quality control.Replaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

General Technical Specifications: Motor Type: Brushless / Brushed DC gear motor Operating Voltage: 12 ~ 24V DC Rated Speed: 20 ~ 70rpm Rated Torque: 1.0N.m ~ 5.0N.m Life time: 2000 ~ 5000 hours Typical Motor Type: 36mm; 42mm diameter long life brushless DC planetary gear motors; 36mm; 42mm diameter brushed DC planetary gear motorsOptional magnetic encoder

Replacement Motor for Lippert LC141893 / LC196308 / M-9000-PK Trailer Landing Gear Motor Heavy Duty DriveReplacement Motor for Stromberg Carlson Electric Landing Gear - 6,500 lbsItem # LC141893 / LC196308 / M-9000-PK12V DC GEARMOTORNo-load Current 3.5ANo-load Speed 200rpmMax. Efficiency Point DataCurrent 18ASpeed 180rpmTorque 7N.mMax. Efficiency 61%Working Point DataCurrent 35ASpeed 158rpmTorque 15N.mGEAR RATIO 35.8:1With Current Limiting Protector ( 40Amps )UL, CE, Reach and RoHS approvalOptional components: magnetic/optical encoder; brake; connectorCustomized shaft dimensions and technical specifications are available upon requestedTypical Applications: High-Speed Power Stabilizer Jack, RV Leveling System, Trailer Leveling System, Trailer Electric Landing Gear
