( P/N 364262 ) 42mm Mid Torque RV In-Wall Slide-Out Motor with Brake 1510000227-Small Gear Motors & Electric Motors

① Characteristics

② Description

RV Slim Rack in-wall Slide-Out Motor with Brake
- 42mm (Mid Torque )  1510000227
Part # 364262

Long & reliable life
CE, UL, RoHS & CCC
100% Exported


Typical technical specs.：

42mm Mid Torque RV In-Wall Slide-Out Motor with Brake ( P/N 364262 ) 1510000227

RV In-Wall Slide Out Motor ( with Brake )

Voltage 12V DC

No-load Speed 26rpm

No-load Current <1.2A

Rated Speed 22rpm

Rated Current 3A

Gear Ratio 294:1

Encoder 4 Pole 2ppr

ELC Brake 0.2N.m, 12V DC
