Products

Motor typeBrush commutated permanent magnet DC motorOptional gearbox typePlanetary/Spur/Worm/Right Angle Diameter60mmLength 95mmNominal voltage12V/24V DC or customizedNo load current0.40A; 0.50A; No load speed2000rpm; 3000rpmNorminal current1.80A; 3.0ANominal speed1600rpm; 2400rpmNominal torque150mN.m; 180mN.mNominal power25W; 40WIP ratingup to IP68

  L2=65MM   L2=156MM

 Motor typeBrush commutated DC motor Gearbox typePlanetary DiameterGearbox: 32mm; DC motor:31mmNominal voltage12V/24V DC or customizedGear ratio 1:3.7 ~1:354No load current70mA; 75mANominal current430mA; 570mANo load speed4000rpm; 5000rpmNominal speed3130rpm; 3830rpmPermissible load range0.3N.m ~ 3.0N.m for S1 duty cycleNominal power7.1W; 9.8WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typePlanetary DiameterGearbox: 56mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:3.6 ~1:76No load current0.80A; 1.10ANominal current7.50A; 9.50ANo load speed3000rpm; 3500rpmNominal speed2400rpm; 2900rpmPermissible load range3.0N.m ~ 30.0N.m for S1 duty cycleNominal power120W; 150WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 80mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.40A; 0.50ANo load speed2000rpm; 3000rpmNominal current1.2A; 2.0ANominal speed1700rpm; 2600rpmPermissible load rangeup to 10.0N.m for S1 duty cycleNominal power18.0W; 33.0WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetary Pole8Phase3DiameterGearbox: 22mm; DC motor: 22mmNominal voltage12V/24V DC or customizedGear ratio 1:3.7 ~1: 369Peak current1.1ANo load speed7000rpmNominal speed4600rpmPermissible load range0.05-1.0N.m for S1 duty cycleRated power3.8W

APPLICATIONS: ·  Elevator /  Lift door openerMOTOR SPECS & FEATURE·  Motor OD Size: 42mm, 52mm, 63mm, 76mm, 80mm·  Voltage: 24V DC·  Power: 30W, 60W, 100W, 190W, 200W, 300W, 400W·  Rated Speed: 800rpm / 1050rpm / 1400rpm / 1600rpm·  Without Gearbox·  Customized shaft & front cover available upon request

RV SEREIS WORM GEAR SPEED REDUCER FEATURE : Compares with other manufacturers, more hardness and stronger for worm & worm wheel and lower noise Available to combine with DC Motor, YY(YN) or IK(RK) Induction Motor, Y Series AC motor, NEMA and IEC ac motor.Reducer Size 025, 030, 050, 063, 075, 090, 110, 130Wide Reduction Ratio 30 ~ 20000Self locking, Fast Stop, IP55Brake available

Description: Applications: Milk ShakerOutlinesRemark: We can produce according to customers requirement.SpecificationsVolts.(V)Freq.(Hz)NO-LOADLOADI.P.(W)O.P. (W)EFF. (%)SPEED(rpm±10%)CURRENT(A)POWER(W)SPEED (rpm±10%)TORQUE(N.m)CURRENT (A)22050/60200000.358068000.21.3227414251.811060198000.77967800.22.8277142.751.5

Vacuum Cleaner Motor Specifications: PARAMETERS/MODELS DYD1400-PB TOLERANCE VALUE RATED VOLTAGE(V) 220/230/240 / RATED FREQUENCY(HZ) 50/60 / RATED INPUT POWER(W) 1400 +10% -5% MAX VACUUM DEGREE(KPA) 26 -5% MAX AIR FLOW(M3/MIN) 3.0 -8% TEMPERATURE RISE(K) ≤90 / NOISE(DB) ≤106 / SPARK <2 / CLASS OF INSULATION E / MAX EFFICIENCY 36% -10% Vacuum Cleaner Motor Dimensions:

Motor typeSingle-Phase AC MotorDiameter AC motor: 90mmOptional gearbox typePlanetary/Spur/Worm/Right Angle Current0.54A~1.55ANominal voltage115V;230VFrequency50Hz/60HzNominal speed1300rpmPermissible load range0.441N.m~0.661N.m for S1 duty cycleNominal power60W~120W

Motor typeSingle-Phase AC MotorDiameter AC motor:60~90mmOptional gearbox typePlanetary/Spur/Worm/Right Angle Nominal voltage115V;230VFrequency50Hz/60HzNominal speed1200rpm;1250rpm;1300rpmPermissible load range32mN.m~294mN.m for S1 duty cycleNominal power4W~40W
