Motor typeBrush commutated DC motor Gearbox typePlanetary DiameterGearbox: 56mm; DC motor: 60mmNominal voltage12V/24V DC or customizedGear ratio 1:3.6 ~1:234No load current0.40A; 0.50ANominal current1.80A; 3.0ANo load speed2000rpm; 3000rpmNominal speed1600rpm; 2400rpmPermissible load range2.0N.m ~ 30.0N.m for S1 duty cycleNominal power25W; 40WIP ratingup to IP68

Model No.VoltageRated PowerRated SpeedRated TorqueRated CurrentNo Load SpeedNo Load CurrentUnitsVWrpmmN.mArpmA52ZY125-1233124730001555.833000.4552ZY125-2433245230001703.033000.2052ZY125-4036405833001702.036000.1552ZY125-6037606034501701.437000.10

52ZY PERMANENT MAGNET DC MOTOR TYPICAL SPECS.:Model No.VoltageRated PowerRated SpeedRated TorqueRated CurrentLUnitsVWrpmmN.m< Amm52ZY12-2012202500782.58152ZY24-2524253000821.552ZY24-2024202500781.252ZY12-20122012001602.590.552ZY40-60406033001752.0125

Reduction ratio292156714741841138323.414.6810.62167137.9Length ( L )      mm27242227242422191919242219Voltage          VDC66612121212121212242424No-load speed  RPM153060530501002003608002060120Rated speed  RPM10.521423.5213570140256560144284Rated torque  kg.cm1.40.750.352.91.450.871.40.510.220.312.90.950.46Rated Current   A0.220.220.220.10.160.160.400.220.200.580.130.130.13

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 60mm; DC motor:60mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.25A; 0.35ANo load speed2000rpm; 3000rpmNominal current1.80A; 2.20ANominal speed1600rpm; 2400rpmPermissible load rangeup to 5.0N.m for S1 duty cycleNominal power30.0W; 45.0WIP ratingup to IP68

51ZY DC BRUSH MOTOR GENERAL SPECS.·  Motor OD: 51mm·  Voltage: 12V DC, 24V DC, 48V DC, 110V DC, 300V DC·  No-load Speed: 2500 ~ 12000RPM·  Input Power: 21 ~ 158W·  Output Power: 5 ~ 42W·  On-load Speed: 2000 ~ 8650RPM·  Without Gearbox·  Customized shaft & front cover available upon request

50ZY DC BRUSH MOTOR TYPICAL SPECS.·  Motor OD: 5·  Voltage: 100V DC·  Power: 7 ~ 13W·  On-load Speed: 1470 ~ 3700RPM·  Without Gearbox·  Customized shaft & front cover available upon request

DC BRUSH MOTOR 52ZY-90W SPECS AND FEATURE: Motor Size: 52mm ODVoltage 12 ~ 36V DC,  110V DC, 220V DCRated Output Power 80 ~ 100WRated Speed 3500 ~ 4000RPMOperation Mode S1

Motor typeBrushless DC motorGearbox typePlanetary Pole10Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:4.44 ~1: 515Nominal current1.2ANo load speed4000rpmNominal speed3000rpmPermissible load range2N.m ~ 20N.m for S1 duty cycleDriverExternal driverRated power21W

Motor typeBrush commutated permanent magnet DC motorOptional gearbox typePlanetary/Spur/Worm/Right Angle Diameter52mmLength 125mmNominal voltage12V/24V DC or customizedNo load current0.40A; 0.60A; 0.80A; No load speed2000rpm; 3000rpm;4000rpmNorminal current2.0A; 3.50A; 4.50ANominal speed1600rpm; 2400rpm; 3200rpmNominal torque160mN.m; 190mN.m; 220mN.m; Nominal power30W; 50W; 80WIP ratingup to IP68

Motor typeNema 17 Hybrid Square Stepper MotorGearbox typePlanetary Phase2Step Angle1.8º or 0.9º or 3.6ºStep Angle Accuracy±5% (full step, no load)Gear ratio 1:3.82 ~1:346Permissible load range6N.m ~ 20N.m for S1 duty cycleTemperature Rise80℃ Max. (rated current, 2 phase on)Ambient Temperature-20℃ ~+50℃Insulation Resistance100MΩ Min., 500V DCDielectric Strength500V AC for one minuteIP ratingup to IP68

Motor typeBrush commutated DC motor with shielding coverGearbox typePlanetary DiameterGearbox: 32mm; DC motor:28mmNominal voltage12V/24V DC or customizedGear ratio 1:3.7 ~1:596No load current150mA; 85mANominal current900mA; 500mANo load speed7300rpmNominal speed5950rpm; 6160rpmPermissible load range0.3N.m ~ 3.0N.m for S1 duty cycleNominal power6.7W; 8.2WIP ratingup to IP68
