Motor typeRare earth magnet DC motorOptional gearbox typePlanetary/Spur/Worm/Right Angle Diameter45mmLength 68mmNominal voltage12V/24V DC or customizedNo load current0.18A; 0.25A; 0.30ANo load speed2000rpm; 3000rpm; 4000rpmNorminal current0.50A; 1.20A; 2.0ANominal speed1600rpm; 2400rpm; 3200rpmNominal torque42mN.m; 65mN.m; 90mN.m; Nominal power7W; 16W; 30WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 60mm; DC motor:52mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:120No load current0.40A; 0.60ANo load speed2000rpm; 3000rpmNominal current2.0A; 3.50ANominal speed1600rpm; 2400rpmPermissible load rangeup to 5.0N.m for S1 duty cycleNominal power30.0W; 50.0WIP ratingup to IP68

Motor typeNema 17 Hybrid Square Stepper MotorGearbox typePlanetary Phase2Step Angle1.8º or 0.9º or 3.6ºStep Angle Accuracy±5% (full step, no load)Gear ratio 1:3.82 ~1:346Permissible load range3N.m ~ 10N.m for S1 duty cycleTemperature Rise80℃ Max. (rated current, 2 phase on)Ambient Temperature-20℃ ~+50℃Insulation Resistance100MΩ Min., 500V DCDielectric Strength500V AC for one minuteIP ratingup to IP68

Motor typeBrush commutated DC motorGearbox typePlanetary DiameterGearbox: 28mm; DC motor:28mmNominal voltage12V/24V DC or customizedGear ratio 1:3.7 ~1:596No load current130mA; 80mANominal current500mA; 300mANo load speed6000rpmNominal speed5200rpm; 5140rpmPermissible load range0.3N.m ~ 3.0N.m for S1 duty cycleNominal power4.2W; 5.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typePlanetary DiameterGearbox: 52mm; DC motor: 52mmNominal voltage12V/24V DC or customizedGear ratio 1:3.6 ~1:135No load current0.40A; 0.60A; 0.80ANominal current2.0A; 3.50A; 4.50ANo load speed2000rpm; 3000rpm; 4000rpmNominal speed1600rpm; 2400rpm; 3200rpmPermissible load range2.0N.m ~ 30.0N.m for S1 duty cycleNominal power30W; 50W; 80WIP ratingup to IP68

Motor typeMicro Brush commutated DC motor Gearbox typeSpurDiameterGearbox: 37mm; DC motor:36mmNominal voltage12V/24V DC or customizedGear ratio 1:6 ~1:3000No load current120mANo load speed3600rpm; 4200rpmNominal current0.50A; 0.52ANominal speed3000rpm; 3600rpmPermissible load rangeup to 1.0N.m for S1 duty cycleNominal power5.0W; 7.0WIP ratingup to IP68

Motor typeBrush commutated DC motorGearbox typeHigh Torque Planetary Gear ReducerDiameterGearbox: 52mm; DC motor: 63mmNominal voltage12V/24V DC or customizedGear ratio1:4.5 ~1:162No load current0.8A; 1.2ANominal current6.5A; 9.0ANo load speed3500rpm; 4000rpmNominal speed2800rpm; 3200rpmPermissible load range0.01N.m ~ 45N.m for S1 duty cycleNominal power100.0W; 150.0WIP ratingup to IP68

Motor typeBrush commutated DC motorGearbox typePlanetaryDiameterGearbox: 52mm; DC motor: 63mmNominal voltage12V/24V DC or customizedGear ratio1:4.5 ~1:162No load current0.4A; 0.5ANominal current4.5A; 6.5ANo load speed3500rpm; 4000rpmNominal speed2800rpm; 3200rpmPermissible load range0.01N.m ~ 45.0N.m for S1 duty cycleNominal power58.0W; 85.0WIP ratingup to IP68

Motor typeCarbon Brush commutated DC motorGearbox typeHigh Torque Planetary Gear ReducerDiameterGearbox: 52mm; DC motor: 63mmNominal voltage12V/24V DC or customizedGear ratio1:4.5 ~1:162No load current0.4A; 0.5ANominal current1.8A; 3.0ANo load speed2000rpm; 3000rpmNominal speed1600rpm; 2400rpmPermissible load range0.01N.m ~ 45.0N.m for S1 duty cycleNominal power25.0W; 40.0WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetary Pole10Phase3DiameterGearbox: 42mm; DC motor: 42mmNominal voltage12V/24V DC or customizedGear ratio 1:3.5 ~1: 294Nominal current1.2ANo load speed4000rpmNominal speed3000rpmPermissible load range2N.m ~ 15N.m for S1 duty cycleDriverExternal driverRated power21W

Motor typeRare earth magnet DC motorOptional gearbox typePlanetary/Spur/Worm/Right Angle Diameter45mmLength 75mmNominal voltage12V/24V DC or customizedNo load current0.25A; 0.30A; No load speed2000rpm; 2500rpm; 3000rpmNorminal current0.80A; 1.70A; 2.50ANominal speed1600rpm; 2000rpm; 2400rpmNominal torque80mN.m; 130mN.m; 150mN.m; Nominal power13W; 25W; 30WIP ratingup to IP68

Motor typeNema 17 Hybrid Square Stepper MotorGearbox typePlanetary Phase2Step Angle1.8º or 0.9º or 3.6ºStep Angle Accuracy±5% (full step, no load)Gear ratio 1:3.82 ~1:346Permissible load range3N.m ~ 15N.m for S1 duty cycleTemperature Rise80℃ Max. (rated current, 2 phase on)Ambient Temperature-20℃ ~+50℃Insulation Resistance100MΩ Min., 500V DCDielectric Strength500V AC for one minuteIP ratingup to IP68
