115ZY PERMANENT MAGNET DC MOTOR TYPICAL SPECS.:Model No.VoltageRated PowerRated SpeedRated TorqueRated CurrentLUnitsVWrpmN.m< Amm115ZY12-1832480030002.645210115ZY24-9202492035002.550115ZY38-4703847018002.517.5115ZY115-85011585021003.711270115ZY130-2400130240045005.025115ZY220-77022077020003.74.5Mounting NEMA 48C, NEMA 56C,  IEC61/71/80 B5/B14, NEMA 143TC/145TC, TENV, TEFC

IEC 71/B14 110ZY DC BRUSH MOTOR GENERAL SPECS.·  Motor OD: 110 mm·  Voltage: 12V DC, 24V DC, 48V DC, 110V DC, 300V DC·  Power: 200W ~ 1250W·  Output Speed: 500 ~ 9000RPM·  Without Gearbox·  Customized shaft & front cover available upon request  (Mounting NEMA 48C, NEMA 56C,  IEC61/71/80 B5/B14, NEMA 143TC/145TC, TENV, TEFC)110ZY DC BRUSH MOTOR TYPICAL SPECS.Model No.VoltageRated PowerRated SpeedRated TorqueRated CurrentNo Load SpeedLengthUnitsVWrpmN.mArpmmm110ZYT24-100024100070001.4055.58000188110ZYT24-6002460030001.9533.03700228110ZYT220-70022070030002.254.03500218

130ZYT DC BRUSH MOTOR GENERAL SPECS.·  Motor OD: 130MM·  Voltage: 12V DC, 24V DC, 48V DC, 60V DC, 110V DC, 300V DC·  Power: 300W ~ 3000W·  Output Speed: 450 ~ 9000RPM·  Without Gearbox·  Customized shaft & front cover (NEMA 56C,  IEC61/71/80 B5/B14, NEMA 143TC/145TC) available upon request130ZY DC BRUSH MOTOR TYPICAL SPECS.Model No.VoltageRated PowerRated SpeedRated TorqueRated CurrentNo Load SpeedLengthUnitsVWrpmN.mArpmmm130ZY246-5601256017503.1059.02000246130ZY275-8004880010007.6422.01250275130ZY306-375123754707.6040.0550306

      Model No.VoltageRated PowerRated SpeedRated TorqueRated CurrentLUnitsVWrpmN.m< Amm160ZYT220-3636200020009.5569220160ZYT230-4848100015006.3730230160ZYT256-2424150015006.8075256160ZYT256-11011085016005.4311256160ZYT310-110130200030006.3724310160ZYT310-220220300030009.5518310Mounting NEMA 48C, NEMA 56C,  IEC61/71/80 B5/B14, NEMA 143TC/145TC, TENV, TEFC

42ZYN NdFeB Magnet DC BRUSH MOTOR TYPICAL SPECS. *  Motor OD: 42mm *  Voltage: 24V DC *  No-load Speed: 4350RPM *  No-load Current: 0.5A *  Rated Output Power: 60W *  Rated Speed: 3300RPM *  Rated Torque: 180mN.m *  Max. Efficiency: 84% *  Custom Higher Power is available upon request (Longer Body or Stronger NdFeB Magnets)Compact Size High Power NdFeB Magnet brushed DC Motor 42ZYN

110ZY195 HIGH VOLTAGE DC BRUSH MOTORS TYPICAL SPECS.:·  Rated Voltage 115V DC (or 220V DC )·  Rated Current <= 6A (or <=4A )·  Rated Output Speed 2630-2900RPM·  Rated Torque 1.8N.m·  Rated Output Power 550W·  Duty Cycle S1·  Insulation Class B·  Rotation: Clockwise (view from the end of output shaft )·  Rated Voltage 120V DC·  Rated Current <= 6A·  Rated Output Speed 1800-2000RPM·  Rated Torque 2.6N.m·  Rated Output Power 550W·  Duty Cycle S1·  Insulation Class B·  Rotation: Clockwise (view from the end of output shaft )·  With Gearbox Available·  Customized shaft & front cover and Customized specs. available upon request
