42ZYN Compact Size High Power NdFeB Magnet brushed DC Motor

① Characteristics

42ZYN NdFeB Magnet DC BRUSH MOTOR TYPICAL SPECS.

*  Motor OD: 42mm
*  Voltage: 24V DC
*  No-load Speed: 4350RPM
*  No-load Current: 0.5A

*  Rated Output Power: 60W
*  Rated Speed: 3300RPM
*  Rated Torque: 180mN.m
*  Max. Efficiency: 84%
*  Custom Higher Power is available upon request (Longer Body or Stronger NdFeB Magnets)

Compact Size High Power NdFeB Magnet brushed DC Motor 42ZYN




② Description
