Motor typeAC Three-Phase MotorGearbox typeSpurDiameter90mm Nominal voltage230V;380VGear ratio 1:3 ~1:180Current0.35A;0.65AFrequency50Hz/60HzNominal speed1300rpm;1500rpmPermissible load rangeUp to 20.0N.m for S1 duty cycleNominal power40W

Motor typeAC Single-Phase MotorGearbox typeSpurDiameter90mm Nominal voltage115V;230VGear ratio 1:3 ~1:180Current0.54A;0.60A;0.98A;1.10AFrequency50Hz/60HzNominal speed1300rpmPermissible load rangeUp to 20.0N.m for S1 duty cycleNominal power60W

Motor typeAC Three-Phase MotorGearbox typeSpurDiameter90mmNominal voltage230V;380VGear ratio 1:3 ~1:180Current0.38A;0.66AFrequency50Hz/60HzNominal speed1300rpmPermissible load rangeUp to  20N.m for S1 duty cycleNominal power90W

Motor typeAC Single-Phase MotorGearbox typeSpurDiameter90mmNominal voltage115V;230VGear ratio 1:3 ~1:180Current0.73A;1.40A;1.55AFrequency50Hz/60HzNominal speed1300rpmPermissible load rangeUp to 20.0N.m for S1 duty cycleNominal power90W

AC Motor 100 Series (6IK140W, 6RK140W) Our standard AC induction gear motors and reversible gear motors includes 4, 6, 10, 15, 20, 25, 30, 40, 60, 90, 120, 140, 180 and 200 Watt motors which can be integrated with 3:1 through 180:1 ratio gear heads (22 different ratios). There are mainly four type: Fixed Speed Motors, Variable Speed Motors, Electromagnetic Brake Motors and Torque Motors. Most of them are directly interchangeable with those made by Oriental Motor, Panasonic Motor, SPG Motor and Bison Gears. These high quality/low cost motors with CE & UL approval shall be your one-stop source for your motion needs.

                        Motor typeAC Brake MotorDiameter60 ~ 90mmBraking torque0.5N.m;1.0N.mPermissible load range5N.m~20.0N.m for S1 duty cycleFrequency50Hz/60HzNominal power6W;10W;15W;25W;40W;60W;90W; 120W

Motor typeSingle-Phase AC MotorDiameter AC motor: 90mmOptional gearbox typePlanetary/Spur/Worm/Right Angle Current0.54A~1.55ANominal voltage115V;230VFrequency50Hz/60HzNominal speed1300rpmPermissible load range0.441N.m~0.661N.m for S1 duty cycleNominal power60W~120W

Motor typeSingle-Phase AC MotorDiameter AC motor:60~90mmOptional gearbox typePlanetary/Spur/Worm/Right Angle Nominal voltage115V;230VFrequency50Hz/60HzNominal speed1200rpm;1250rpm;1300rpmPermissible load range32mN.m~294mN.m for S1 duty cycleNominal power4W~40W

Motor typeThree-Phase AC MotorDiameter AC motor:90mmOptional gearbox typePlanetary/Spur/Worm/Right Angle Current0.35A;0.38A;0.65A;0.66ANominal voltage230V;380V;400VFrequency50Hz/60HzNominal speed1300rpm;1500rpmPermissible load range0.37N.m~0.661N.m for S1 duty cycleNominal power60W~120W

Motor typeThree-Phase AC MotorDiameter AC motor:70~90mmOptional gearbox typePlanetary/Spur/Worm/Right Angle Current0.12A;0.20A;0.25A;0.38A;0.40ANominal voltage230V;380V;400VFrequency50Hz/60HzNominal speed1200rpm;1300rpm;1550rpmPermissible load range0.122N.m~0.25N.m for S1 duty cycleNominal power15W~40W

AC PARALLEL SHAFT GEAR MOTOR YN80-25/77JB SPECS AND FEATURE: 230V AC, 60HZMotor Power 25W Motor Rated Speed 1500RPMGear Ratio 37.2/1Class BDuty Cycle: Continuous

AC PLANETARY GEARMOTOR 82JX1200K329/90YN60-2CF SPECS & FEATURE90mm OD AC Motor 82mm OD Planetary GearheadVoltage 230V Single-PhaseFrequency 50HzMotor Output Power 60WRated Current 0.4ARated Speed 3.9RPMRated Torque 110N.mGear Ratio 329/1
