60YJB100K/45ZY68 PM DC Spur Gearmotor

① Characteristics

Motor typeBrush commutated DC motor
Gearbox typeSpur
SizeGearbox: 60mm; DC motor45mm
Nominal voltage12V/24V DC or customized
Gear ratio 1:3 ~1:200
No load current0.20A; 0.25A
No load speed2000rpm; 3000rpm
Nominal current0.50A; 0.80A
Nominal speed1600rpm; 2400rpm
Permissible load rangeup to 10.0N.m for S1 duty cycle
Nominal power5.0W; 10.0W
IP ratingup to IP68


② Description

DC spur gear motor

The 45ZY68 model of brushed DC motor is equipped with a 60mm round spur gearbox

Options

Magnetic encoder or optical encoder with up to 3 channels provides feedback for your accurate control of motor speed and positioning.

Power-on or power-off type electromagnetic brake

Capacitor& resistor for EMC suppression

Special shaft material and dimensions

Custom design; OEM products available

Features

Ball bearing at output shaft

Magnetic field generated by permanent magnets

Operation in both directions of rotation(CW & CCW)

Speeds up to 10,000 RPM possible

Various gear ratios enable either speed reduction or to increase the torque capability

Advantageous torque with minimum space requirements

Suitable for continuous, reversing and intermittent operation

Can be installed in any mounting position

Typical applications

Industrial automation: conveyers, rotational operation, automatic gate system, solar tracker etc.

Household electrical appliances:lawn mower, ice crusher, stair lift, air-condition, masticating juicer, food waste disposer, kitchen appliances, etc.,

The automotive industry: truck tarp systems, pumps, electric chair, jack, etc.

Recreational equipment: swimming pool cleaners, pool cover systems, golf trolley, amusement machines and other places of entertainment, etc.

Office automation: automatic doors, elevator doors, roller shutter, curtains, punch machines, financial instruments, etc.

Medical and health-care equipment: all kinds of massage health care equipment, medical equipment, etc.

Certificates & Qualifications

REACH, CE & CCC, RoHS, ISO9001: 2015, ISO14001: 2015, OHSAS18001: 2007
