IP67 Brushless DC Worm Gear Motors

① Characteristics

Brushless DC Tarp Gear Motors w/Chrome Cover

BLDC Tarp Motors

CANVAS-TOP TRUCK BRUSHLESS DC MOTORS

Dump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.


TARP MOTOR 80ZWN-12/JW-7 SPECS AND FEATURE (GEAR RATIO 60:1):

  • 3 years warranty

  • Hi-torque, direct drive 12VDC (or 24VDC) motor (output torque 600 in-lbs)

  • 60:1 gear ratio.

  • 60 RPM (+/-6RPM)

  • Power 600W ( L=214.5mm ) or 900W ( L=218.5mm, Model 80ZWNS-12/JW-7 )

  • Waterproof IP67

  • Epoxy sealed gearbox maintains lubrication.

  • 3-1/8" x 3/4" extended output shaft fits wide range of tarp systems.

  • Sealed drive shaft and encased bearing prevents contamination.

  • Chrome/plastic cover and fasteners included.

  • 100% tested for quality control.



BRUSHLESS DC TARP MOTOR 80ZWN-12/JW-7 SPECS AND FEATURE (GEAR RATIO 90:1):


  • 3 years warranty

  • Hi-torque, direct drive 12VDC (or 24VDC) motor (output torque 800 in-lbs)

  • 90:1 gear ratio.

  • 40 RPM (+/-5RPM)

  • Power 600W ( L=214.5mm ) or 900W ( L=218.5mm, Model 80ZWNS-12/JW-7 )

  • Waterproof IP67

  • Epoxy sealed gearbox maintains lubrication.

  • 3-1/8" x 3/4" extended output shaft fits wide range of tarp systems.

  • Sealed drive shaft and encased bearing prevents contamination.

  • Chrome/plastic cover and fasteners included.

  • 100% tested for quality control.

  • Replaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.
