Tarp Gear Motor w/Chrome Cover Dump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.600W TARP MOTOR 80ZYT-12/JW-7 SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 600 in-lbs)90:1 gear ratio.No-load Speed 55RPM / Rated Speed 40 RPM (+/-5RPM)Power 600W (Motor body Length 116mm) or 900W (Motor body Length 141mm, Model 80ZYTS-12/JW-7 )Epoxy sealed gearbox maintains lubrication.2-1/2" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.Waterproof Level IP65100% tested for quality control.Optional 24V DC, Gear Ratio 60:1 or 45:1, 900W/1.2HP, 1200W/1.5HP, 2.0HP, 2.5HPAmbient temperature of minus 40° available upon requestReplaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

Industrial Door Locking DC Gear Motor / DC Linear ActuatorModel: DYD38ZY73-1223-250-30Typical Specs.: 12VDC, Force 250N.m, No-Speed 25mm/S, Stroke 30mmApplication: Industrial Door Locking

Tarp Gear Motor w/Chrome Cover Dump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.900W TARP MOTOR 80ZYT-12/JW-7 SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 800 in-lbs)90:1 gear ratio.No-load Speed 55RPM / Rated Speed 40 RPM (+/-5RPM)Power 600W (Motor body Length 116mm) or 900W (Motor body Length 141mm, Model 80ZYTS-12/JW-7 )Epoxy sealed gearbox maintains lubrication.2-1/2" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.Waterproof Level IP65100% tested for quality control.Ambient temperature of minus 40° available upon requestOptional 24V DC, Gear Ratio 60:1 or 45:1, 600W/0.8HP, 1200W/1.5HP, 2.0HP, 2.5HPReplaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

Brushless DC Tarp Gear Motors w/Chrome CoverBLDC Tarp Motors CANVAS-TOP TRUCK BRUSHLESS DC MOTORSDump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.TARP MOTOR 80ZWN-12/JW-7 SPECS AND FEATURE (GEAR RATIO 60:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 600 in-lbs)60:1 gear ratio.60 RPM (+/-6RPM)Power 600W ( L=214.5mm ) or 900W ( L=218.5mm, Model 80ZWNS-12/JW-7 )Waterproof IP67Epoxy sealed gearbox maintains lubrication.3-1/8" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.100% tested for quality control.BRUSHLESS DC TARP MOTOR 80ZWN-12/JW-7 SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 800 in-lbs)90:1 gear ratio.40 RPM (+/-5RPM)Power 600W ( L=214.5mm ) or 900W ( L=218.5mm, Model 80ZWNS-12/JW-7 )Waterproof IP67Epoxy sealed gearbox maintains lubrication.3-1/8" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.100% tested for quality control.Replaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

Replacement Gear Motor for Bulldog Electric Powered-Drive KitItem # BD1046130-00   ( Our model: DZ76ZYC03B ), 500370, 1824200100, 1824210100, 1046131, 104613012V DC GEARMOTORRED WIRE LEAD +12V CW ROTATION, VIEW FROM DIRECTION A18.75 FT-LBS @ 14AMPS AND 32RPMGEAR RATIO 99:11 piece per EPE foam cartonWeight 5.5KGS/pcCarton size 471*256*141mmP/N 500370  ( 1046130 )

IP67 FUEL PUMP MOTOR GENERAL SPECS.  DC 24V  No-Load Speed 5000RPM  Rated Output Speed 3500RPM   Rated Output Power 300W   Insulation Class B   IP67 or IP69K  Customized shaft & front cover available upon request

Replacement Motor for Lippert LC141893 / LC196308 / M-9000-PK Trailer Landing Gear Motor Heavy Duty DriveReplacement Motor for Stromberg Carlson Electric Landing Gear - 6,500 lbsItem # LC141893 / LC196308 / M-9000-PK12V DC GEARMOTORNo-load Current 3.5ANo-load Speed 200rpmMax. Efficiency Point DataCurrent 18ASpeed 180rpmTorque 7N.mMax. Efficiency 61%Working Point DataCurrent 35ASpeed 158rpmTorque 15N.mGEAR RATIO 35.8:1With Current Limiting Protector ( 40Amps )UL, CE, Reach and RoHS approvalOptional components: magnetic/optical encoder; brake; connectorCustomized shaft dimensions and technical specifications are available upon requestedTypical Applications: High-Speed Power Stabilizer Jack, RV Leveling System, Trailer Leveling System, Trailer Electric Landing Gear

136373  RV Slide Out Motor 28:1 Ratio 8532-08JModel: 63ZY116-1257/160JB28GItem # 136373, 8532-08JVoltage 12V DCNo-load Current 2.5ANo-load Speed 5800rpmMax. Efficiency Point Data:Current 20ASpeed 160rpmTorque 8.0N.mMax. Efficiency 60%Gear Ratio 28 : 1Max. Current 30AWith Current Limiting ProtectorUL, CE, Reach and RoHS approvalOptional components: magnetic/optical encoder; brake; connectorCustomized shaft dimensions and technical specifications are available upon requestedTypical Applications: High-Speed Power Stabilizer Jack, RV Leveling System, Trailer Leveling System
